Capacitive touch sensor

Capacitive touch sensor uses its remarkable patented FFT (Film Free Technology) to maintain accuracy and robustness in a variety of harsh environments over the life of the product. Capacitive sensors provide a solution for high-use applications that demand reliable, accurate and sensitive touches performances. Capacitive touch sensor surface with protective hard coat enables scratch-resistance and contaminant-resistance to dirt, dust, liquids and corrosive chemicals. Capacitive sensors have been tested to withstand over than 300 million touches in a single location without noticeable degradation.

Point of sales Application

ATM
Industrial Automation
Kiosk
Gaming / Amusement
Vending
Point-of-Sale (POS) Terminals

Specification

MECHANICAL	Available Size	10.4” to 19”
	Input Method	Finger
	Glass Thickness	3mm (for sensor size above 10.4”)
ELECTRICAL	Insulation Resistance	20M O or more @ DC 25V
	Chattering Time	10 ms or less
	Linearity	±1.5% error or less for X axis ±1.5% error or less for Y axis
OPTICAL	Transmittance	85% to 93% per ASTM D1003 Equipment used: BYK Gardner Haze Gard Plus
OPTICAL	Surface Finish	Anti-glare or polish
ENVIRONMENTAL	Temperature	Operating:-20? to 70?
	Temperature	Storage:-40? to 85?
	High Temperature and Humidity Chemical Resistance	70? and 90% RH for 120hours Resistance to corrosives, in accordance with ASTM-D-1308 and ASTM-D-F-1598
DURABILITY	Surface Hardness	Can not be scratched using any stylus with Mohs' rating of 6 or lessExceeds severe abrasion test per MIL-C-675C
DURABILITY	Touch Life	More than 300M touches in a single location
