Developed Five-Wire technology with the harshest
environments in mind, so it's no wonder that it excels in reliability,
durability, and expected product life. Impervious to environmental
conditions such as liquid spills and splashes, humidity, and washdown,
these screens are the most contamination-resistant available. They
deliver drift-free operation for a lifetime of 35 million finger
touches.
|
 |
Application
1 |
|
5Wire technology is the workhorse of
resistive touchscreens, providing unsurpassed performance in
POS, industrial, medical, and transportation applications. Touch
the screen with a finger, gloved hand, fingernail, or object
such as a credit card, and you'll receive a fast, accurate
response every time.
|
|
Point of sales Application
|
|
- Fine Dining
- Fast Food
- Hospitality
- Lodging
- Vending
- Lottery Terminals
- General Retail
-
Grocery/Convenience
|
-
Process Control
-
Food Processing Equipment
-
Machine Control
-
Industrial PCs
-
Man-Machine Interface
-
Office Automation Equipment
-
Automated Testing
-
Automobile
Test Equipment
|
|
|
Specification
|
|
|
Mechanical
|
Available Size |
6.4" to 21.3"; visit our
Web site for full specifications and other offerings
|
|
Input Method |
Finger, gloved hand, or
stylus activation
|
|
Electrical
|
Positional Accuracy
|
Standard deviation error is less than
0.080 (2 mm)
|
|
Resolution
|
Touch point density is based on
controller resolution of 4096 x 4096
|
|
Touch Activation Force
|
Typically less than 4 ounces (113 grams)
|
|
Controller
|
Board: Serial (RS232) and USB 1.1
Chip: Serial (RS232) and USB
|
|
Optical
|
Transmittance |
HL products: 80% +/–5% at 550 nm
wavelength Enhanced products: 60% +/–5% at 550 nm
|
|
Environmental
|
Temperature
and Humidity |
Operating:90% RH at max 35°C (standard design)
90% RH at max 50°C
(enhanced design) |
Storage: 90% RH at max 35°C for 240 hrs,
no condensing (standard design)
90% RH at max 50°C for 240 hrs, no condensing (enhanced design) |
|
Altitude
|
Operating: 10,000 ft (3,048 m)
Storage/transport: 50,000 ft(15,240 m)
|
|
Chemical Resistance
|
Industrial chemicals: acetone, methylene chloride, methyl ethyl ketone, isopropyl alcohol, hexane, turpentine, mineral spirits, unleaded
gasoline, diesel fuel, motor oil, transmission fluid, antifreeze. Food-service chemicals: vinegar, coffee, tea, grease, cooking oil, salt, plus most
commercial cleaners including ammonia-based glass cleaner and laundry detergent. |
|
Durability
|
Surface Durability
|
3H per ASTM D3363 |
|
Touch Life |
Operationally tested to
35 million touches in one location without failure
|
|
|
|
 |
