Features
|
Features
|
- Specially Designed for Public Access
Terminals
- Water & Dust Proof Design
- 4 Function Keys (DEL, CTRL, ALT, WIN) on
Rear Side of Keyboard
- Laser Engraved Legends for Different
Characters
- Tactile Feeling, Full Traveling of 2 -
3mm
- PS2/USB (Optional) Interface
|
-
Specifically Designed for The Public Environment
-
Water and Dust Proof Design
-
Front Plate : Zinc Alloy With Cr Coating, Froggy
Treated Surface
-
Connection : PS/2 Interface
-
Operating Temperature : 0°C-45"C
-
Package Dimension : L158xW122 x H50mm
|
| Material |
|
-
Front Plate
: Zinc Alloy With Cr Coating, Foggy Treated
Surface
-
Key tops
: With 40 jm of Zinc Alloy Electro-Coating
Mounted in a Stainless Steel Fascia
-
Total Key Travel
: 2-3mm, Just Like Normal Keyboard
|
|
| Electrial |
|
-
Supply Voltage
: 5Vdc±0.25V
-
Supply Current
: Max,300 mA
-
Connection
: 4pin Mini-DIN, Cable Length 1.3m
|
|
|
Environment |
|
-
Operating Temperature
: D°C - 50°C
-
Insulating Impedance
: 1000MQ, 1KVdc
-
Package Dimension
: L300 x W140 x H48 mm
|
|
|
